Indoor Digital Signage Media Player Ultra-Thin High-Brightness LCD Display Screen
Featuring ultra-thin bezels, high brightness up to 1500 nits, and true 4K UHD resolution, this series is built to deliver stunning visual clarity and reliability in various indoor environments. With a sleek design, versatile mounting options, and robust Android-based system, the Q6 series is ideal for advertising, information display, interactive kiosks, and seamless video wall setups.
Available Sizes & Models
| Model |
Size |
Resolution |
Brightness |
Contrast |
Power Consumption |
| 8343Q6 |
43" |
4K UHD |
1000 cd/㎡ |
1200:1 |
≤190W |
| 8355Q6 |
55" |
4K UHD |
1000 cd/㎡ |
1200:1 |
≤232W |
| 8365Q6 |
65" |
4K UHD |
1000 cd/㎡ |
1300:1 |
≤270W |
| 8375Q6 |
75" |
4K UHD |
1000 cd/㎡ |
1300:1 |
≤364W |
| 8386Q6 |
86" |
4K UHD |
1000 cd/㎡ |
1300:1 |
≤548W |
Key Features
- 4K Ultra HD Resolution – 3840 × 2160 pixels for crystal-clear imagery
- High Brightness & Uniformity – Up to 1000 cd/㎡ (configurable to 700/1500 nits) with excellent screen uniformity
- Ultra-Narrow Bezel – Only 6.9mm bezel width for minimal visual interruption, perfect for multi-screen setups
- Ultra-Thin Design – OD12 mixed-light technology enables an extremely slim profile, ideal for wall-mounting
- Wide Viewing Angle – 178° horizontal and vertical for clear visibility from almost any position
- Android 11 Smart System – Powered by RK3566 quad-core processor, 2GB RAM + 32GB storage, supporting flexible app installation and content management
- Versatile Connectivity – Includes USB 3.0, USB 2.0 OTG, RJ45 Ethernet, Wi-Fi 6, and Bluetooth 5.0
- Image Rotation Support – Software-enabled 0°, 90°, 180°, 270° screen rotation for portrait or landscape use
- Long Service Life – 30,000 hours of reliable operation with low power consumption
- Wide Compatibility – Supports PAL/NTSC/SECAM video formats and multiple audio systems
4K Ultra HD
3840×2160 resolution delivers crisp text, vivid images, and accurate color reproduction (16.7M).
Every frame looks professional and engaging.
Ultra-Narrow Bezel
The evenly matched 6.9mm bezel on all four sides maximizes screen area and minimizes distraction.
Ideal for single displays or seamless video walls.
High Brightness
With up to 1000 cd/m² standard (configurable to 700 or 1500 nits).
Q6 remains clearly visible even in brightly lit retail spaces, lobbies, or storefronts.
Wide 178° Viewing Angle
Colors and contrast remain uniform across a full 178° horizontal and vertical range.
Your content looks great from any angle.
Versatile Connectivity
Includes USB 3.0, USB 2.0 OTG, RJ45 Ethernet, Wi-Fi 6, and Bluetooth 5.0.
Easy integration with existing systems and networks.
